 ¢º SBS LM GUIDE (SBM(S) Miniature type)




Model No.¡¡

External dimensions

LM-block dimensions

Height
H


E


W©ü

Width
W

Length
L

Mounting tab hole


L©û


K


T
1

Grease nipple

B X J

M X §¤

Mouniing hole

SBM(S) 9

10

2.2

5.5

20

32

15x10

M3x3

18

7.8

2.3

Ø2

SBM(S)L 9

10

2.2

5.5

20

43.8

15x16

M3x3

29.8

7.8

2.3

Ø2

SBM(S) 12

13

3

7.5

27

36.8

20x15

M3x3.5

23

10

2.7

Ø2

SBM(S)L 12

13

3

7.5

27

47.1

20x20

M3x3.5

33.3

10

2.7

Ø2

SBM(S) 15

16

4

8.5

32

44

25x20

M3x4

29

12

3.1

Ø3

SBM(S)L 15

16

4

8.5

32

58.5

25x25

M3x4

43.5

12

3.1

Ø3

Model No.

LM-rail dimensions

Load capacity

Weight

Width
W1

Height
H1

Pitch

Bolt hole
dxDxh

G

Max
Lengths
Lomax

Dynamic
C(kgf)

Stationary
Co(kgf)

stationary moment(kgf¤ým)

Bearing
(kgf)

Rail
(kgf/m)

MRo

MPo

Mro

SBM(S) 9

9

5.3

20

2.6x4.5x3

7.5

610

160

240

0.52

0.52

1.06

0.018

0.32

SBM(S)L 9

9

5.3

20

2.6x4.5x3

7.5

610

265

400

1.87

1.79

1.79

0.027

0.32

SBM(S) 12

12

7.35

25

3.5x6x4.5

10

610

250

370

0.82

0.89

1.5

0.037

0.58

SBM(S)L 12

12

7.35

25

3.5x6x4.5

10

610

430

670

2.72

2.45

2.66

0.055

0.58

SBM(S) 15

15

9.5

40

3.5x6x4.5

15

610

410

610

1.68

1.83

3.08

0.069

0.925

SBM(S)L 15

15

9.5

40

3.5x6x4.5

15

610

730

1090

5.41

5.03

5.46

0.093

0.925
