Á¦Ç°¼Ò°³ : LM GUIDE > SBC LM °¡À̵å |
SBG-FLÇü
(°íÇÏÁßÇü)
| SBG-SLÇü
(°íÇÏÁßÇü)
| SBG-FLLÇü (ÃÊ°íÇÏÁßÇü)
| SBG-SLLÇü (ÃÊ°íÇÏÁßÇü) |
¢º SBG LM
GUIDE (SL Çü)
|
¢º SLÇü(°íÇÏÁßÇü) ´ÜÀ§ :mm
±âº»¹øÈ£ | Á¶¸³Ä¡¼ö | ºí ·° Ä¡ ¼ö | |||||||||||
³ôÀÌ H | E | W2 | Æø W | ±æÀÌL | ¼³Ä¡ ÅDZ¸¸Û | L1 | K | T | ±¸¸®½º´ÏÇà | ||||
B×J | M | ¼³Ä¡±¸¸Û | T1 | N | |||||||||
28 | 2.65 | 9.5 | 34 | 58.8 | 26×26 | M4X5 | 38.8 | 25.35 | 8 | ø3.5 | 8 | 5 | |
30 | 3.5 | 12 | 44 | 77.2 | 32×36 | M5X8 | 50.8 | 26.5 | 8 | M6×0.75 | 7 | 9.8 | |
40 | 5 | 12.5 | 48 | 86.9 | 35×35 | M6X8 | 59.5 | 35 | 12 | M6×0.75 | 10.5 | 9.8 | |
45 | 6.5 | 16 | 60 | 98 | 40×40 | M8X10 | 70.4 | 38.5 | 12 | M6×0.75 | 11.5 | 10.7 | |
55 | 7.5 | 18 | 70 | 109.5 | 50×50 | M8X12 | 80.4 | 47.5 | 15 | M6×0.75 | 16.5 | 10.7 | |
70 | 7.3 | 20.5 | 86 | 136 | 60×60 | M10X17 | 98 | 62.7 | 15 | PT1/8 | 20.5 | 11 | |
80 | 9.8 | 23.5 | 100 | 160 | 75×75 | M12X18 | 118 | 70.2 | 18 | PT1/8 | 22 | 11 | |
90 | 17.5 | 31.5 | 126 | 189 | 76×70 | M16X20 | 147 | 72.5 | 23 | PT1/8 | 15 | 11 |
¡Ø °¢ ¸ðµ¨ÀÇ Ä³µåµµ¸éÀ» ´Ù¿î·Îµå ¹ÞÀ¸½Ç¼ö ÀÖ½À´Ï´Ù.
·¹ÀÏÄ¡¼ö | ±âº» Á¤°Ý ÇÏÁß | Áß·® | ±âº»¹øÈ£ | ||||||||||
·¹ÀÏÆø | ·¹ÀÏ | ÇÇÄ¡ | ¼³Ä¡º¼Æ®±¸¸Û | G | ·¹ÀÏÃÖ´ë±æÀÌ | µ¿Á¤°Ý | Á¤Á¤°Ý | Á¤¸ð¸ÕÆ®(kgf.m) | º£¾î¸µ | ·¹ÀÏ | |||
MRO | MPO | Mro | |||||||||||
15 | 15 | 60 | 4.5×7.5×5.3 | 20 | 3,000 | 850 | 1370 | 7 | 5 | 5 | 0.2 | 1.45 | SBG 15 SL |
20 | 17.5 | 60 | 6×9.5×8.5 | 20 | 4,000 | 1450 | 2560 | 22 | 18 | 18 | 0.33 | 2.20 | SBG 20 SL |
23 | 21.8 | 60 | 7×11×9 | 20 | 4,000 | 2140 | 4000 | 36 | 32 | 31 | 0.56 | 3.10 | SBG 25 SL |
28 | 25 | 80 | 9×14×12 | 20 | 4,000 | 2980 | 5490 | 60 | 50 | 49 | 0.98 | 4.45 | SBG 30 SL |
34 | 29 | 80 | 9×14×12 | 20 | 4,000 | 3960 | 7010 | 96 | 75 | 73 | 1.63 | 6.40 | SBG 35 SL |
45 | 38 | 105 | 14×20×17 | 22.5 | 4,000 | 6290 | 11292 | 202 | 159 | 157 | 2.96 | 11.25 | SBG 45 SL |
53 | 45 | 120 | 16×23×20 | 30 | 4,000 | 9307 | 16012 | 344 | 274 | 270 | 4.52 | 15.25 | SBG 55 SL |
63 | 58.5 | 150 | 18×26×22 | 35 | 3,000 | 15100 | 24500 | 629 | 495 | 484 | 6.55 | 23.90 | SBG 65 SL |
|
|
