SBG-FLÇü
(°íÇÏÁßÇü)
| SBG-SLÇü
(°íÇÏÁßÇü)
| SBG-FLLÇü (ÃÊ°íÇÏÁßÇü)
|
SBG-SLLÇü (ÃÊ°íÇÏÁßÇü) |
¢º SBG LM
GUIDE (FLL ÃÊ°íÇÏÁßÇü)
|
¢º FLLÇü(°íÇÏÁßÇü) ´ÜÀ§ :mm
±âº»¹øÈ£ | Á¶¸³Ä¡¼ö | ºí ·° Ä¡ ¼ö | ||||||||||||
³ôÀÌ H | E | W2 | Æø W | ±æÀÌL | ¼³Ä¡ ÅDZ¸¸Û | L1 | K | T | ±¸¸®½º´ÏÇà | |||||
B×J | M | S | ¼³Ä¡±¸¸Û | T1 | N | |||||||||
30 | 3.5 | 21.5 | 63 | 93.2 | 53×40 | M6 | M5 | 66.8 | 26.5 | 9 | M6×0.75 | 7 | 9.8 | |
36 | 5 | 23.5 | 70 | 106.4 | 57×45 | M8 | M6 | 79 | 31 | 10 | M6×0.75 | 6.5 | 9.8 | |
42 | 6.5 | 31 | 90 | 120.5 | 72×52 | M10 | M8 | 92.9 | 35.5 | 12 | M6×0.75 | 8.5 | 10.7 | |
48 | 7.5 | 33 | 100 | 135 | 82×62 | M10 | M8 | 105.9 | 40.5 | 13 | M6×0.75 | 9.5 | 10.7 | |
60 | 7.3 | 37.5 | 120 | 168 | 100×80 | M12 | M10 | 130 | 52.7 | 15 | PT1/8 | 10.5 | 11 | |
70 | 9.8 | 43.5 | 140 | 198 | 116×95 | M14 | M12 | 156 | 60.2 | 17 | PT1/8 | 12 | 11 | |
90 | 17.5 | 53.5 | 170 | 249 | 142×110 | M16 | M14 | 207 | 72.5 | 23 | PT1/8 | 15 | 11 |
¡Ø °¢ ¸ðµ¨ÀÇ Ä³µåµµ¸éÀ» ´Ù¿î·Îµå ¹ÞÀ¸½Ç¼ö ÀÖ½À´Ï´Ù.
·¹ÀÏÄ¡¼ö | ±âº» Á¤°Ý ÇÏÁß | Áß·® | ±âº»¹øÈ£ | ||||||||||
·¹ÀÏÆø | ·¹ÀÏ | ÇÇÄ¡ | ¼³Ä¡º¼Æ®±¸¸Û | G | ·¹ÀÏÃÖ´ë±æÀÌ | µ¿Á¤°Ý | Á¤Á¤°Ý | Á¤¸ð¸ÕÆ®(kgf.m) | º£¾î¸µ | ·¹ÀÏ | |||
MRO | MPO | Mro | |||||||||||
20 | 17.5 | 60 | 6×9.5×8.5 | 20 | 4,000 | 1725 | 3730 | 29 | 32 | 32 | 0.54 | 2.20 | SBG 20 FLL |
23 | 21.8 | 60 | 7×11×9 | 20 | 4,000 | 2517 | 4905 | 44 | 50 | 49 | 0.78 | 3.10 | SBG 25 FLL |
28 | 25 | 80 | 9×14×12 | 20 | 4,000 | 3602 | 6929 | 75 | 81 | 80 | 1.44 | 4.45 | SBG 30 FLL |
34 | 29 | 80 | 9×14×12 | 20 | 4,000 | 4701 | 9225 | 126 | 133 | 131 | 2.14 | 6.40 | SBG 35 FLL |
45 | 38 | 105 | 14×20×17 | 22.5 | 4,000 | 7714 | 14138 | 250 | 238 | 235 | 3.75 | 11.25 | SBG 45 FLL |
53 | 45 | 120 | 16×23×20 | 30 | 4,000 | 11413 | 20068 | 427 | 413 | 405 | 5.68 | 15.25 | SBG 55 FLL |
63 | 58.5 | 150 | 18×26×22 | 35 | 3,000 | 19300 | 32700 | 834 | 850 | 830 | 9.5 | 23.90 | SBG 65 FLL |
|
|
