With
standard seals
With
preload 7% or 10% C
For
precision-rolled screws SN-R of
tolerance
grade T5, T7, T9 and groundthread
screws
SN-F of tolerance grade P1, P3, P5, (T7)
|
|
|
d0 :
nominal diameter P : lead(R=right-hand, L=left-hend)
Dw :
ball diameter i = number of ball track turns |
|
Size |
Part number |
Load ratings |
|
d0 x P x Dw-
i |
dyn. |
stat. |
|
C(N) |
C0(N) |
|
16 x 5 R x
3-4 |
1502-0-1033 |
12300 |
16100 |
|
20 x 5 R x
3-4 |
1502-1-1023 |
14300 |
21500 |
|
25 x 5 R x
3-4 |
1502-2-1023 |
15900 |
27200 |
|
25 x 10 R x
3-4 |
1502-2-4023 |
15700 |
27000 |
|
32 x 5 R x
3.5-4 |
1502-3-1023 |
21600 |
40000 |
|
32 x 10 R x
3.969-5 |
1502-3-4033 |
31700 |
58300 |
|
40 x 5 R x
3.5-5 |
1502-4-1023 |
29100 |
64100 |
|
40 x 10 R x
6-4 |
1502-4-4033 |
50000 |
86400 |
|
40 x 10 R x
6-6 |
1502-4-4034
|
72100
|
132200
|
|
40 x 20 R x
6-3 |
1502-4-7033 |
37900 |
62800 |
|
50 x 5 R x
3.5-5 |
1502-5-1023 |
32000 |
81300 |
|
50 x 10 R x
6-4 |
1502-5-4033 |
55400 |
109000 |
|
50 x 10 R x
6-6 |
1502-5-4034 |
79700 |
166500 |
|
50 x 20 R x
6.5-5 |
1502-5-7034 |
32100 |
55800 |
|
63 x 10 R x
6-4 |
1502-6-4033 |
61800 |
140500 |
|
63 x 10 R x
6.6 |
1502-6-4034 |
88800 |
214300 |
|
63 x 20 R x
6.5-2 |
1502-6-7034 |
83900 |
190300 |
|
80 x 10 R x
6.5-6 |
1502-7-4024 |
108400 |
291700 |
|
80 x 20 R x
9-6 |
1502-7-7034 |
170900 |
403900 |
|
80 x 20 R x
12.7-6 |
1502-7-7024 |
262700 |
534200 |
|
100 x 10 R x
6.5-6 |
1502-8-4024
|
119500
|
371900
|
|
100 x 20 R x
12.7-6 |
1502-8-7024
|
295100
|
686400
|
|
125 x 10 R x
6.5-6 |
1502-9-4024
|
130600
|
468700
|
|
125 x 20 R x
12.7-6 |
1502-9-7024
|
326500
|
870400
|
|
|
|
|
|
|
|
|
|
Size
d0 x P
x Dw-i |
Dimensions (mm)
|
Weight
m
(Kg)
|
|
d1 |
d2 |
D1
f9 |
D5 |
Hole
pattern |
D6 |
D7 |
L |
L3 |
L4 |
L10 |
S |
|
16 x 5 R x
3-4 |
15.0 |
12.9 |
28 |
5.3 |
BB3
|
40 |
7 |
72 |
12 |
10 |
60 |
M6 |
0.33 |
|
20 x 5 R x
3-4 |
19.0 |
16.9 |
33 |
58 |
BB4
|
45 |
7 |
82 |
12 |
10 |
70 |
M6 |
0.45 |
|
25 x 5 R x
3-4 |
24.0 |
21.9 |
38 |
63 |
BB4
|
50 |
7 |
82 |
12 |
10 |
70 |
M6 |
0.53 |
|
25 x 10 R x
3-4 |
24.0 |
21.9 |
38 |
63 |
BB4
|
50 |
7 |
120 |
12 |
16 |
108 |
M6 |
0.70 |
|
32 x 5 R x
3.5-4 |
31.0 |
28.4 |
48 |
73 |
BB4
|
60 |
7 |
88 |
13 |
10 |
75 |
M6 |
0.84 |
|
32 x 10 R x
3.969-5 |
31.0 |
27.9 |
48 |
73 |
BB4
|
60 |
7 |
146 |
13 |
16 |
133 |
M6 |
1.22 |
|
40 x 5 R x
3.5-5 |
39.0 |
36.4 |
56 |
80 |
BB4
|
68 |
7 |
100 |
15 |
10 |
85 |
M8x1 |
1.13 |
|
40 x 10 R x
6-4 |
38.0 |
33.8 |
63 |
95 |
BB4
|
78 |
9 |
140 |
15 |
16 |
125 |
M8x1 |
2.25 |
|
40 x 10 R x
6-6 |
38.0
|
33.8
|
63
|
95
|
BB4
|
78
|
9
|
180
|
15
|
16
|
164
|
M8x1 |
2.83
|
|
40 x 20 R x
6-3 |
38.0 |
33.8 |
63 |
95 |
BB4
|
78 |
9 |
175 |
15 |
25 |
160 |
M8x1 |
2.66 |
|
50 x 5 R x
3.5-5 |
49.0 |
46.4 |
68 |
98 |
BB4
|
82 |
9 |
100 |
15 |
10 |
85 |
M8x1 |
1.60 |
|
50 x 10 R x
6-4 |
48.0 |
43.8 |
72 |
110 |
BB4
|
90 |
11 |
140 |
18 |
16 |
122 |
M8x1 |
2.74 |
|
50 x 10 R x
6.6 |
48.0 |
43.8 |
72 |
110 |
BB4
|
90 |
11 |
180 |
18 |
16 |
162 |
M8x1 |
3.39 |
|
50 x 20 R x
6.5-5 |
48.0 |
43.4 |
85 |
125 |
BB4
|
105 |
11 |
255 |
22 |
25 |
233 |
M8x1 |
6.71 |
|
63 x 10 R x
6-4 |
61.0 |
56.8 |
85 |
125 |
BB4
|
105 |
11 |
140 |
22 |
16 |
118 |
M8x1 |
3.53 |
|
63 x 10 R x
6-6 |
61.0 |
56.8 |
85 |
125 |
BB4
|
105 |
11 |
180 |
22 |
16 |
158 |
M8x1 |
4.32 |
|
63 x 20 R x
6.5-5 |
61.0 |
56.4 |
95 |
140 |
BB4
|
118 |
14 |
255 |
22 |
25 |
233 |
M8x1 |
8.65 |
|
80 x 10 R x
6.5-6 |
78.0 |
73.3 |
105 |
150 |
BB4
|
125 |
14 |
190 |
22 |
16 |
168 |
M8x1 |
6.35 |
|
80 x 20 R x
9-6 |
77.0 |
70.8 |
125 |
180 |
BB5
|
152 |
18 |
320 |
25 |
25 |
295 |
M8x1 |
18.60 |
|
80 x 20 R x
12.7-6 |
76.0 |
67.0 |
125 |
180 |
BB5
|
152 |
18 |
340 |
25 |
25 |
315 |
M8x1 |
20.20 |
|
100 x 10 R x
6.5-6 |
98.0
|
93.4
|
125
|
180
|
BB5
|
152
|
18
|
190
|
25
|
16
|
165
|
M8x1 |
8.19
|
|
100 x 20 R x
12.7-6 |
96.0
|
87.1
|
145
|
200
|
BB5
|
172
|
18
|
340
|
30
|
25
|
310
|
M8x1 |
24.50
|
|
125 x 10 R x
6.5-6 |
123.0
|
118.0
|
150
|
210
|
BB5
|
180
|
18
|
190
|
30
|
16
|
160
|
M8x1 |
10.80
|
|
125 x 20 R x
12.7-6 |
121.0
|
112.0
|
170
|
230
|
BB6
|
200
|
18
|
340
|
40
|
25
|
300
|
M8x1 |
31.00
|
|
|
|
