CODE

TYPE

W

L

BOLTHOLE

Fixing Bolt

a

b

c

d

Size

Q'TY

SL-20 x 100

C

20

100

60

-

-

-

M8

2

SL-20 x 150

C

20

150

55

55

-

-

M8

3

SL-20 x 200

C

20

200

55

50

55

-

M8

4

SL-30 x 100

B

30

100

60

-

-

-

M10

2

SL-30 x 150

B

30

150

55

55

-

-

M10

3

SL-30 x 200

B

30

200

55

50

55

-

M10

4

SL-30 x 250

B

30

250

70

70

70

-

M10

4

SL-45 x 200

A

45

200

55

50

55

-

M10

4

SL-45 x 250

A

45

250

70

70

70

-

M10

4

SL-45 x 300

A

45

300

65

65

65

65

M10

5

SL-45 x 350

A

45

350

80

75

75

80

M10

5
