GUIDE SR-W and SR-WM Type -Standard
Type
SR-V
SR-VM -Stainless-steel Type |
|

|
|
|
|
Model
No. |
External
dimensions |
LM-block
dimensions |
|
height
M |
width
W |
length
L |
B |
C |
S× |
L1 |
T |
K |
N |
E |
grease
nipple |
| *SR 15 W/WM
*SR 15 V/VM |
24 |
34 |
57
41 |
26 |
26
- |
M4×7 |
39.5
22.9 |
6 |
19.5 |
6 |
5.5 |
PB1021B |
| *SR 20 W/WM
*SR 20 V/VM |
28 |
42 |
66.5
48 |
32 |
32
- |
M5×8 |
46.7
27.8 |
7.5 |
22 |
6 |
12 |
B-M6F |
| *SR 25 WY/WMY
*SR 25 VY/VMY |
33 |
48 |
83
60 |
35 |
35
- |
M6×9 |
59
35.2 |
8 |
26 |
7 |
12 |
B-M6F |
| *SR 30 W/WM
*SR 30 V/VM |
42 |
60 |
97
68 |
40 |
40
- |
M8×12 |
69.3
40.4 |
9 |
32.5 |
8 |
12 |
B-M6F |
| *SR 35 W/WM
*SR 35 V/VM |
48 |
70 |
111
78 |
50 |
50
- |
M8×12 |
79
45.7 |
13 |
36.5 |
8.5 |
12 |
B-M6F |
| SR 45 W |
60 |
86 |
126 |
60 |
60 |
M10×15 |
90.5 |
15 |
47.5 |
11.5 |
16 |
B-PT1/8 |
| SR 55 W |
68 |
100 |
156 |
75 |
75 |
M12×20 |
117 |
17 |
54.5 |
12 |
16 |
B-PT1/8 |
| SR 70 T |
85 |
126 |
195 |
90 |
90 |
M16×25 |
147.6 |
25 |
70 |
12 |
16 |
B-PT1/8 |
| SR 85 T |
110 |
156 |
180 |
100 |
80 |
M18×30 |
130 |
25 |
91.5 |
27 |
12 |
A-PT1/8 |
| SR 100 T |
120 |
178 |
200 |
120 |
100 |
M20×35 |
150 |
30 |
101 |
32 |
12 |
A-PT1/8 |
| SR 120 T |
110 |
205 |
235 |
160 |
120 |
M20×35 |
180 |
24 |
95 |
14 |
13.5 |
B-PT1/4 |
| SR 150 T |
135 |
250 |
280 |
200 |
160 |
M20×35 |
215 |
24 |
113 |
17 |
13.5 |
B-PT1/4 | |
|
|
|
Model
No. |
LM-rail
dimensions |
Basic
load rating |
Mass |
|
width
W1
±0.05 |
W2 |
height
M1 |
pitch
F |
d1×d2×h |
C
kN |
C0
kN |
LM
block
kg |
LM
rail
kg/m |
| *SR 15 W/WM
*SR 15 V/VM |
15 |
9.5 |
12.5 |
60 |
3.5×6×4.5 |
9.51
5.39 |
19.3
11.1 |
0.2
0.12 |
1.2 |
| *SR 20 W/WM
*SR 20 V/VM |
20 |
11 |
15.5 |
60 |
6×9.5×8.5 |
12.5
7.16 |
25.2
14.4 |
0.3
0.2 |
2.1 |
| *SR 25 WY/WMY
*SR 25 VY/VMY |
23 |
12.5 |
18 |
60 |
7×11×9 |
20.3
11.7 |
39.5
22.5 |
0.4
0.3 |
2.7 |
| *SR 30 W/WM
*SR 30 V/VM |
28 |
16 |
23 |
80 |
7×11×9 |
30
17.2 |
56.8
32.5 |
0.8
0.5 |
4.3 |
| *SR 35 W/WM
*SR 35 V/VM |
34 |
18 |
27.5 |
80 |
9×14×12 |
41.7
23.8 |
77.2
44.1 |
1.2
0.8 |
6.4 |
| SR 45 W |
45 |
20.5 |
35.5 |
105 |
11×17.5×14 |
55.3 |
101 |
2.2 |
11.3 |
| SR 55 W |
48 |
26 |
38 |
120 |
14×20×17 |
89.1 |
157 |
3.6 |
12.8 |
| SR 70 T |
70 |
28 |
47 |
150 |
18×26×22 |
156 |
266 |
7.0 |
22.8 |
| SR 85 T |
85 |
35.5 |
65.5 |
180 |
18×26×22 |
120 |
224 |
10.1 |
34.9 |
| SR 100 T |
100 |
39 |
70.3 |
210 |
22×32×25 |
148 |
283 |
14.1 |
46.4 |
| SR 120 T |
114 |
45.5 |
65 |
230 |
26×39×30 |
279 |
377 |
- |
- |
| SR 150 T |
144 |
53 |
77 |
250 |
33×48×36 |
411 |
537 |
- |
- | |
|
|
