| ▶LM
GUIDE
SHS-C(Heavy
load type) SHS-LC(Ultra-heavy-load
type)
|
|

|
|
|
|
Model
No. |
External
dimensions |
LM-block
dimensions |
|
height
M |
width
W |
length
L |
B |
C |
S |
H |
L1 |
T |
T1 |
K |
N |
E |
grease
nipple |
| SHS 15 C
SHS 15 LC |
24 |
47 |
64.4
79.4 |
38 |
30 |
M5 |
4.4 |
48
63 |
6 |
8 |
21 |
5.5 |
5.5 |
PB1021B |
| SHS 20 C
SHS 20 LC |
30 |
63 |
79
98 |
53 |
40 |
M6 |
5.4 |
59
78 |
7.2 |
10 |
25.4 |
6.5 |
12 |
B-M6F |
| SHS 25 C
SHS 25 LC |
36 |
70 |
92
109 |
57 |
45 |
M8 |
6.8 |
71
88 |
9 |
12 |
30.2 |
7.5 |
12 |
B-M6F |
| SHS 30 C
SHS 30 LC |
42 |
90 |
106
131 |
72 |
52 |
M10 |
8.5 |
80
105 |
12 |
15 |
35 |
8 |
12 |
B-M6F |
| SHS 35 C
SHS 35 LC |
48 |
100 |
122
152 |
82 |
62 |
M10 |
8.5 |
93
123 |
12 |
15 |
40.5 |
8 |
12 |
B-M6F |
| SHS 45 C
SHS 45 LC |
60 |
120 |
140
174 |
100 |
80 |
M12 |
10.5 |
106
140 |
14 |
18 |
51.1 |
10.5 |
16 |
B-PT1/8 |
| SHS 55 C
SHS 55 LC |
70 |
140 |
171
213 |
116 |
95 |
M14 |
12.5 |
131
173 |
17 |
21 |
57.3 |
11 |
16 |
B-PT1/8 |
| SHS 65 C
SHS 65 LC |
90 |
170 |
221
272 |
142 |
110 |
M16 |
14.5 |
175
226 |
20 |
24 |
71 |
19 |
16 |
B-PT1/8 |
|
|
Model
No. |
Pilot hole for
the side nipple |
LM-rail
dimensions |
Basic
load rating |
Mass |
|
U |
J |
D |
width
|
W2 |
height
M1 |
pitch
F |
d1×d2×h |
C
kN |
C0
kN |
LM
block
kg |
LM
rail
kg/m |
| SHS 15 C
SHS 15 LC |
4.2 |
4 |
3 |
15 |
16 |
13 |
60 |
4.5×7.5×5.3 |
9.8
12.5 |
24.2
31.9 |
0.23
0.29 |
1.3 |
| SHS 20 C
SHS 20 LC |
5.7 |
5.3 |
3 |
20 |
21.5 |
16.5 |
60 |
6×9.5×8.5 |
15.9
20.9 |
38.4
50.3 |
0.46
0.61 |
2.3 |
| SHS 25 C
SHS 25 LC |
4.5 |
5.5 |
3 |
23 |
23.5 |
20 |
60 |
7×11×9 |
22.1
27.3 |
52.4
64.7 |
0.72
0.89 |
3.2 |
| SHS 30 C
SHS 30 LC |
7.5 |
6 |
5.2 |
28 |
31 |
23 |
80 |
9×14×12 |
30.8
38.9 |
66.6
88.8 |
1.34
1.66 |
4.5 |
| SHS 35 C
SHS 35 LC |
8 |
5.5 |
5.2 |
34 |
33 |
26 |
80 |
9×14×12 |
42.5
55.9 |
96.6
127 |
1.9
2.54 |
6.2 |
| SHS 45 C
SHS 45 LC |
9 |
8 |
5.2 |
45 |
37.5 |
32 |
105 |
14×20×17 |
56.4
74.2 |
126
166 |
3.24
4.19 |
10.4 |
| SHS 55 C
SHS 55 LC |
10 |
8 |
5.2 |
53 |
43.5 |
38 |
120 |
16×23×20 |
90.5
119 |
197
259 |
5.35
6.97 |
14.5 |
| SHS 65 C
SHS 65 LC |
13 |
12 |
5.2 |
63 |
53.5 |
53 |
150 |
18×26×22 |
150
192 |
320
408 |
10.7
13.7 |
23.7 |
|
|
