¢º LM GUIDE: RSR-ZM





Model No.

External
dimensions

LM-block dimensions

height
M

width
W

length
L

B

C

L1

T

K

N

E

grease
nipple
(oil hole)

RSR 7 ZM

8

17

23.4

12

8

M2×2.5

13.2

3.7

6.5

1.6

-

¥õ1.5 drilled hole

RSR 9 ZM

10

20

30.8

15

10

M3×2.7

19.4

4.7

7.8

2.4

-

¥õ1.6 drilled hole

RSR 12 ZM

13

27

35.0

20

15

M3×3.2

20.4

4.8

10.6

3.1

-

¥õ2 drilled hole

RSR 15 ZM

16

32

43.0

25

20

M3×3.5

26.5

5.8

12.6

2.9

3.6

driven-in nipple
PB107

          ¡Ø Download CAD Files

Model No.

LM-rail dimensions

Basic load rating

Mass

W1

W2

M1

F

d1×d2×h

C
kN

C0
kN

LM block
kg

LM rail
kg/m

RSR 7 ZM

7

 0
-0.02

5

4.7

15

2.4×4.2×2.3

0.88

1.37

0.008

0.23

RSR 9 ZM

9

 0
-0.02

5.5

5.5

20

3.5×6×3.3

1.47

2.25

0.014

0.32

RSR 12 ZM

12

 0
-0.025

7.5

7.5

25

3.5×6×4.5

2.65

4.02

0.028

0.58

RSR 15 ZM

15

 0
-0.025

8.5

9.5

40

3.5×6×4.5

4.41

6.57

0.050

0.925





Type-RSR-Z/RSR-WZ LM-Rail Standard and Maximum Lengths

Model No.

RSR 7 Z

RSR 9 Z

RSR 12 Z

RSR 15 Z

RSR 7 WZ

RSR 9 WZ

RSR 12 WZ

RSR 15 WZ

LM-rail
standard
length
(L
0)

40
55
70
85
100
130

55
75
95
115
135
155
175
195
275
375

70
95
120
145
170
195
220
245
270
320
370
470
570

70
110
150
190
230
270
310
350
390
430
470
550
670
870

50
80
110
140
170
200
260
290

50
80
110
140
170
200
260
290
320

70
110
150
190
230
270
310
390
470
550

110
150
190
230
270
310
430
550
670
790
