LM
GUIDE: RSR-VM / RSR-M / RSR-N (Stainless
Steel Type)
|
|
|
|
Model
No. |
External dimensions |
LM-block
dimensions |
height M |
width W |
length L |
B |
C |
S× |
L1 |
T |
K |
N |
E |
grease nipple (oil
hole) |
RSR 5 M RSR 5 N |
6 |
12 |
17 20 |
8 - |
- 7 |
M2×1.5 M2.6×1.8 |
8.8 12 |
- |
4.5 |
0.8 |
- |
¥õ0.8drilled hole |
RSR 7 M RSR 7 N |
8 |
17 |
23.5 33 |
12 |
8 13 |
M2×2.5 |
13.4 23 |
- |
6.5 |
1.7 |
- |
- |
RSR 9 KM RSR 9 N |
10 |
20 |
31 41 |
15 |
10 16 |
M3×3.0 |
19.8 29.8 |
- |
7.8 |
- |
- |
- |
RSR 12 VM RSR 12 N |
13 |
27 |
35 48 |
20 |
15 20 |
M3×3.5 |
20.6 33.3 |
- |
10 |
3 |
- |
¥õ2drilled hole |
RSR 15 VM RSR 15 N |
16 |
32 |
43 61 |
25 |
20 25 |
M3×4 |
25.7 43.5 |
- |
12 |
3.5 |
3.6 3.7 |
PB107 |
RSR 20 VM RSR 20 N |
25 |
46 |
66.5 86.5 |
38 |
38 38 |
M4×6 |
45.2 65 |
6 |
17.5 |
5 |
6.4 |
A-M6F | |
|
Model
No. |
LM-rail
dimensions |
Basic
load rating
|
Mass |
W1 |
W2 |
M1 |
F |
d1×d2×h |
C N |
C0 N |
LM block kg |
LM rail kg/m |
RSR 5 M RSR 5 N |
|
3.5 |
4 |
15 |
2.4×3.5×1 |
320 550 |
590 960 |
0.003 0.004 |
0.14 |
RSR 7 M RSR 7 N |
|
5 |
4.7 |
15 |
2.4×4.2×2.3 |
880 1590 |
1370 2500 |
0.013 0.018 |
0.23 |
RSR 9 KM RSR 9 N |
|
5.5 |
5.5 |
20 |
3.5×6×3.3 |
1470 2600 |
2250 3960 |
0.018 0.027 |
0.32 |
RSR 12 VM RSR 12 N |
|
7.5 |
7.5 |
25 |
3.5×6×4.5 |
2650 4300 |
4020 6650 |
0.037 0.055 |
0.58
|
RSR 15 VM RSR 15 N |
|
8.5 |
9.5 |
40 |
3.5×6×4.5 |
4410 7160 |
6570 10700 |
0.069 0.093 |
0.925 |
RSR 20 VM RSR 20 N |
|
13 |
15 |
60 |
6×9.5×8.5 |
8820 14200 |
12700 20600 |
0.245 0.337 |
1.95 | |
|
|
|
