¢ºLM
GUIDE
RHS-M(Stainless Steel
Type) |
|
|
Model
No. |
External dimensions |
LM-block
dimensions |
height M
|
width W
|
length L
|
B
|
C
|
S× |
L 1
|
K
|
N
|
Oil
hole |
RSH 7 M
|
8
|
17
|
23.5
|
12
|
8
|
M2×2.5
|
13.4
|
6.5
|
1.7
|
¥õ1.2 |
RSH 9 KM
|
10
|
20
|
31
|
15
|
10
|
M3×3.0
|
19.8
|
7.8
|
2.4
|
¥õ1.5 |
RSH 12 VM
|
13
|
27
|
35
|
20
|
15
|
M3×3.5
|
20.6
|
10
|
3
|
¥õ2 | |
|
Model
No. |
LM-rail
dimensions |
Basic
load rating
|
Mass |
W1
|
W2
|
M1
|
F
|
d1×d2×h
|
C N
|
C0 N
|
LM block kg
|
LM rail kg/m
|
RSH 7 M
|
|
5
|
4.7
|
15
|
2.4×4.2×2.3
|
880
|
1370
|
0.010
|
0.23
|
RSH 9 KM
|
|
5.5
|
5.5
|
20
|
3.5×6×3.3
|
1470
|
2250
|
0.018
|
0.32
|
RSH 12 VM
|
|
7.5
|
7.5
|
25
|
3.5×6×4.5
|
2650
|
4020
|
0.037
|
0.58
| |
|
|
|
