Unit : mm
|
Rail
length L |
Stroke
length S |
MIN/MAX |
Motor
side A |
Opposite
motor side B |
W |
1 |
2 |
KR 33 |
200 |
29 |
16/48 |
48 |
47 |
84 |
130 |
76 |
300 |
114 |
25/139 |
54 |
56 |
400 |
194 |
35/229 |
64 |
66 |
500 |
264 |
50/321 |
79 |
81 |
600 |
344 |
60/404 |
89 |
91 |
KR 46 |
340 |
90 |
15.5/111.5 |
73 |
67 |
110 |
191 |
110 |
440 |
168 |
29.5/197.5 |
81 |
81 |
540 |
248 |
39.5/287.5 |
91 |
91 |
640 |
318 |
54.5/372.5 |
106 |
106 |
740 |
408 |
59.5/467.5 |
111 |
111 |
940 |
548 |
89.5/637.5 |
141 |
141 |
KR 55 |
980 |
652 |
50.4/702.4 |
100 |
100 |
154 |
223.1 |
128 |
1080 |
738 |
57.4/795.4 |
107 |
107 |
1180 |
826 |
63.4/889.4 |
113 |
113 |
1280 |
912 |
70.4/982.4 |
120 |
120 |
1380 |
998 |
77.4/1075.4 |
127 |
127 |
KR 65 |
980 |
625.5 |
46/671.5 |
103 |
106.5 |
184 |
255 |
145 |
1180 |
795.5 |
61/856.5 |
118 |
121.5 |
1380 |
959.5 |
79/1038.5 |
136 |
139.5 |
1680 |
1211.5 |
103/1314.5 |
160 |
163.5 | |
