GUIDE HSR-A (Heavey-load type) HSR-AM
HSR-LA
(Ultra-heavey-load type)
HSR-LAM |
|

|
|
|
|
Model
No. |
External
dimensions |
LM-block
dimensions |
|
height
M |
width
W |
length
L |
B |
C |
S× |
L1 |
T |
T1 |
K |
N |
E |
grease
nipple |
| HSR 15 A
*HSR 15 AM |
24 |
47 |
56.6 |
38 |
30 |
M5×0.8×11 |
38.8 |
7 |
11 |
19.3 |
4.3 |
5.5 |
PB1021B |
| HSR 20 A
*HSR 20 AM |
30 |
63 |
74 |
53 |
40 |
M6×10 |
50.8 |
10 |
10 |
26 |
5 |
12 |
B-M6F |
| HSR 20 LA
*HSR 20 LAM |
30 |
63 |
90 |
53 |
40 |
M6×10 |
66.8 |
10 |
10 |
26 |
5 |
12 |
B-M6F |
| HSR 25 A
*HSR 25 AM |
36 |
70 |
83.5 |
57 |
45 |
M8×16 |
59.5 |
10 |
16 |
30.5 |
6 |
12 |
B-M6F |
| HSR 25 LA
*HSR 25 LAM |
36 |
70 |
102.5 |
57 |
45 |
M8×16 |
78.6 |
10 |
16 |
30.5 |
6 |
12 |
B-M6F |
| HSR 30 A
*HSR 30 AM |
42 |
90 |
98 |
72 |
52 |
M10×18 |
70.4 |
10 |
18 |
35 |
7 |
12 |
B-M6F |
| HSR 30 LA
*HSR 30 LAM |
42 |
90 |
121 |
72 |
52 |
M10×18 |
93 |
10 |
18 |
35 |
7 |
12 |
B-M6F |
| HSR 35 A
*HSR 35 AM |
48 |
100 |
109.5 |
82 |
62 |
M10×21 |
80.4 |
13 |
21 |
40.5 |
8 |
12 |
B-M6F |
| HSR 35 LA
*HSR 35 LAM |
48 |
100 |
135 |
82 |
62 |
M10×21 |
105.8 |
13 |
21 |
40.5 |
8 |
12 |
B-M6F |
| HSR 45 A
HSR 45 LA |
60 |
120 |
139
171 |
100 |
80 |
M12×15 |
98
129.8 |
14 |
25 |
50 |
10 |
16 |
B-PT1/8 |
| HSR 55 A
HSR 55 LA |
70 |
140 |
163
201 |
116 |
95 |
M14×17 |
118
156.1 |
15 |
29 |
57 |
11 |
16 |
B-PT1/8 |
| HSR 65 A
HSR 65 LA |
90 |
170 |
186
246 |
142 |
110 |
M16×23 |
147
206.5 |
23 |
37 |
76 |
19 |
16 |
B-PT1/8 |
| HSR 85 A
HSR 85 LA |
110 |
215 |
247
303 |
185 |
140 |
M20×30 |
178.6
236 |
30 |
55 |
94 |
23 |
16 |
B-PT1/8 | |
|
|
|
Model
No. |
LM-rail
dimensions |
Basic
load rating |
Mass |
|
width
W1
±0.05 |
W2 |
height
M1 |
pitch
F |
d1×d2×h |
C
kN |
C0
kN |
LM block
kg |
LM rail
kg/m |
| HSR 15 A
*HSR 15 AM |
15 |
16 |
15 |
60 |
4.5×7.5×5.3 |
8.33 |
13.5 |
0.2 |
1.5 |
| HSR 20 A
*HSR 20 AM |
20 |
21.5 |
18 |
60 |
6×9.5×8.5 |
13.8 |
23.8 |
0.35 |
2.3 |
| HSR 20 LA
*HSR 20 LAM |
20 |
21.5 |
18 |
60 |
6×9.5×8.5 |
21.3 |
31.8 |
0.47 |
2.3 |
| HSR 25 A
*HSR 25 AM |
23 |
23.5 |
22 |
60 |
7×11×9 |
19.9 |
34.4 |
0.59 |
3.3 |
| HSR 25 LA
*HSR 25 LAM |
23 |
23.5 |
22 |
60 |
7×11×9 |
27.2 |
45.9 |
0.75 |
3.3 |
| HSR 30 A
*HSR 30 AM |
28 |
31 |
26 |
80 |
9×14×12 |
28 |
46.8 |
1.1 |
4.8 |
| HSR 30 LA
*HSR 30 LAM |
28 |
31 |
26 |
80 |
9×14×12 |
37.3 |
62.5 |
1.3 |
4.8 |
| HSR 35 A
*HSR 35 AM |
34 |
33 |
29 |
80 |
9×14×12 |
37.3 |
61.1 |
1.6 |
6.6 |
| HSR 35 LA
*HSR 35 LAM |
34 |
33 |
29 |
80 |
9×14×12 |
50.2 |
81.5 |
2.0 |
6.6 |
| HSR 45 A
HSR 45 LA |
45 |
37.5 |
38 |
105 |
14×20×17 |
60
80.4 |
95.6
127 |
2.8
3.3 |
11.0 |
| HSR 55 A
HSR 55 LA |
53 |
43.5 |
44 |
120 |
16×23×20 |
88.5
119 |
137
183 |
4.5
5.7 |
15.1 |
| HSR 65 A
HSR 65 LA |
63 |
53.5 |
53 |
150 |
18×26×22 |
141
192 |
215
286 |
8.5
10.7 |
22.5 |
| HSR 85 A
HSR 85 LA |
85 |
65 |
65 |
180 |
24×35×28 |
210
282 |
310
412 |
17.0
23.0 |
35.2 | |
|
|
