GUIDE: HRW - CA HRW - CAM Standard
Type / Stainless-steel Type |
|
|
Model
No. |
External dimensions |
LM-block
dimensions |
height M |
width W |
L
|
B |
C |
S |
H |
h1 |
L1 |
T |
K |
N |
E |
grease nipple |
HRW 17 CA HRW 17 CAM |
17 |
60 |
51 |
53 |
26 |
M4 |
3.3 |
3.2 |
33.6 |
6 |
14.5 |
4 |
2 |
PB107 |
HRW 21 CA HRW 21 CAM |
21 |
68 |
59 |
60 |
29 |
M5 |
4.4 |
3.7 |
40 |
8 |
18 |
4.5 |
12 |
B-M6F |
HRW 27 CA HRW 27 CAM |
27 |
80 |
73 |
70 |
40 |
M6 |
5.3 |
6 |
51.8 |
10 |
24 |
6 |
12 |
B-M6F |
HRW 35 CA HRW 35 CAM |
35 |
120 |
107.5 |
107 |
60 |
M8 |
6.8 |
8 |
77.6 |
14 |
31 |
8 |
12 |
B-M6F |
HRW 50 CA |
50 |
162 |
141.5 |
144 |
80 |
M10 |
8.6 |
14 |
103.5 |
18 |
46.6 |
14 |
16 |
B-PT1/8 |
HRW 60 CA |
60 |
200 |
159 |
180 |
80 |
M12 |
10.5 |
15.5 |
117.5 |
25 |
53.5 |
15 |
16 |
B-PT1/8 | |
|
Model
No. |
LM-rail
dimensions |
Basic
load rating |
Mass |
width W1 ±0.05 |
W2 |
W3 |
height M1 |
pitch F |
d1×d2×h |
C kN |
C0 kN |
LM block kg |
LM rail kg/m |
HRW 17 CA HRW 17 CAM |
33 |
13.5 |
18 |
9 |
40 |
4.5×7.5×5.3 |
4.31 |
8.14 |
0.15 |
2.1 |
HRW 21 CA HRW 21 CAM |
37 |
15.5 |
22 |
11 |
50 |
4.5×7.5×5.3 |
6.18 |
11.5 |
0.25 |
2.9 |
HRW 27 CA HRW 27 CAM |
42 |
19 |
24 |
15 |
60 |
4.5×7.5×5.3 |
11.5 |
20.4 |
0.5 |
4.3 |
HRW 35 CA HRW 35 CAM |
69 |
25.5 |
40 |
19 |
80 |
7×11×9 |
27.2 |
45.9 |
1.4 |
9.9 |
HRW 50 CA |
90 |
36 |
60 |
24 |
80 |
9×14×12 |
50.2 |
81.5 |
4.0 |
14.6 |
HRW 60 CA |
120 |
40 |
80 |
31 |
105 |
11×17.5×14 |
63.8 |
102 |
5.7 |
27.8 | |
|
|
|
