LM
GUIDE HSR-YR |
|
|
Model
No. |
External dimensions |
LM-block
dimensions |
height M |
width W |
length L |
B1 |
B |
C |
S× |
L1 |
K |
N |
E |
grease nipple |
HSR 15 YR *HSR 15 YRM |
28 |
33.5 |
56.6 |
4.3 |
11.5 |
18 |
M4×0.7×5 |
38.8 |
23.3 |
8.3 |
5.5 |
PB1021B |
HSR 20 YR *HSR 20 YRM |
30 |
43.5 |
74 |
4 |
11.5 |
25 |
M5×0.8×6 |
50.8 |
26 |
5 |
12 |
B-M6F |
HSR 25 YR *HSR 25 YRM |
40 |
47.5 |
83.5 |
6 |
16 |
30 |
M6×6 |
59.5 |
34.5 |
10 |
12 |
B-M6F |
HSR 30 YR *HSR 30 YRM |
45 |
59.5 |
98 |
8 |
16 |
40 |
M6×9 |
70.4 |
38 |
10 |
12 |
B-M6F |
HSR 35 YR *HSR 35 YRM |
55 |
69.5 |
109.5 |
8 |
23 |
43 |
M8×10 |
80.4 |
47 |
15 |
12 |
B-M6F |
HSR 45 YR |
70 |
85.5 |
139 |
10 |
30 |
55 |
M10×14 |
98 |
60 |
20 |
16 |
B-PT1/8 |
HSR 55 YR |
80 |
99.5 |
163 |
12 |
32 |
70 |
M12×15 |
118 |
67 |
21 |
16 |
B-PT1/8 |
HSR 65 YR |
90 |
124.5 |
186 |
12 |
35 |
85 |
M16×22 |
147 |
76 |
19 |
16 |
B-PT1/8 | |
|
Model
No. |
LM-rail
dimensions |
Basic
load rating |
Mass |
width W1 ±0.05 |
W2 |
height M1 |
pitch F |
d1×d2×h |
C kN |
C0 kN |
LM block kg |
LM rail kg/m |
HSR 15 YR *HSR 15 YRM |
15 |
24 |
15 |
60 |
4.5×7.5×5.3 |
8.33 |
13.5 |
0.18 |
1.5 |
HSR 20 YR *HSR 20 YRM |
20 |
31.5 |
18 |
60 |
6×9.5×8.5 |
13.8 |
23.8 |
0.25 |
2.3 |
HSR 25 YR *HSR 25 YRM |
23 |
35 |
22 |
60 |
7×11×9 |
19.9 |
34.4 |
0.54 |
3.3 |
HSR 30 YR *HSR 30 YRM |
28 |
43.5 |
26 |
80 |
9×14×12 |
28 |
46.8 |
0.9 |
4.8 |
HSR 35 YR *HSR 35 YRM |
34 |
51.5 |
29 |
80 |
9×14×12 |
37.3 |
61.1 |
1.5 |
6.6 |
HSR 45 YR |
45 |
65 |
38 |
105 |
14×20×17 |
60 |
95.6 |
2.6 |
11.0 |
HSR 55 YR |
53 |
76 |
44 |
120 |
16×23×20 |
88.5 |
137 |
4.3 |
15.1 |
HSR 65 YR |
63 |
93 |
53 |
150 |
18×26×22 |
141 |
215 |
7.3 |
22.5 | |
|
|
|
