¢ºLM
GUIDE: GSR - T (long type) GSR - VÇü
(short type)
|
|
|
Model
No. |
External dimensions |
LM-block
dimensions |
height M |
width W |
length L |
B |
B1 |
C |
N-S× |
K1 |
K2 |
L1 |
N1 |
N2 |
E |
grease nipple |
GSR 15 T GSR 15 V |
20 |
32 |
60 47.1 |
15 |
5 |
26 - |
4-M4×0.7×7 2-M4×0.7×7 |
12 |
17.5 |
40.2 27.5 |
4.5 |
3 |
5.5 |
PB-107 |
GSR 20 T GSR 20 V |
24 |
43 |
74 58.1 |
20 |
7 |
30 - |
4-M5×0.8×8 2-M5×0.8×8 |
13.6 |
20.6 |
50.2 34.3 |
5 |
- |
12 |
B-M6F |
GSR 25 T GSR 25 V |
30 |
50 |
88 69 |
23 |
7 |
40 - |
4-M6×10 2-M6×10 |
16.8 |
25.5 |
60.2 41.2 |
7 |
- |
12 |
B-M6F |
GSR 30 T |
33 |
57 |
103 |
26 |
8 |
45 |
4-M8×12 |
18 |
28.5 |
70.3 |
7 |
- |
12 |
B-M6F |
GSR 35 T |
38 |
68 |
117 |
32 |
9 |
50 |
4-M8×15 |
20.5 |
32.5 |
80.3 |
8 |
- |
12 |
B-M6F | |
|
Model
No. |
LM-rail
dimensions |
Basic
load rating |
Mass |
width W1 |
W2 |
B2 |
height M1 |
pitch F |
d1×d2×h |
C kN |
C0 kN |
LM
block kg |
LM
rail kg/m |
GSR 15 T GSR 15 V |
15 |
25 |
7.5 |
11.5 |
60 |
4.5×7.5×5.3 |
5.69 4.31 |
8.43 5.59 |
0.13 0.08 |
1.2 |
GSR 20 T GSR 20 V |
20 |
33 |
10 |
13 |
60 |
6×9.5×8.5 |
9.22 7.01 |
13.2 8.82 |
0.25 0.17 |
1.8 |
GSR 25 T GSR 25 V |
23 |
38 |
11.5 |
16.5 |
60 |
7×11×9 |
13.5 10.29 |
19.0 12.65 |
0.5 0.29 |
2.6 |
GSR 30 T |
28 |
44.5 |
14 |
19 |
80 |
9×14×12 |
18.8 |
25.9 |
0.6 |
3.6 |
GSR 35 T |
34 |
54 |
17 |
22 |
80 |
11×17.5×14 |
25.1 |
33.8 |
1.0 |
5.0 | |
|
|
|
